Multifunctional pipe fitting up machine

It mainly used for mechanical fitting up of pipes +pipes, pipes +elbows, pipes +flanges, pipes +tees, etc.
The fitting up platform can move up/down, left/right, forward/ backward, as well as rotate in 360°.
The fitting up platform can also be used for flange fitting up.
The machine can be combined in different types to suitable for different pipe spools in different industries.
If adopting two fitting up platforms with pipe supporters, the machine can be used for elbow-pipe-elbow fitting up.
It reduces labor and improves the accuracy of fitting up, providing accurate tacking welding joints for the next welding step and improving the qualification rate of automatic welding.

Product Detail

Model	QZPMG-16	QZPMG-24	QZPMG-32	QZPMG-40	QZPMG-48
Suitable for pipe size	DN50-400	DN100-600	DN100-800	DN200-1000	DN300-1200
Lifting stroke	≤200mm	≤200mm	≤200mm	≤300mm	≤300mm
Forward/backward stroke	≤300mm	≤300mm	≤300mm	≤400mm	≤400mm
Multi-function fitting up platform	motorized forward/backward; left/right; lifting, 360°rotating
